Cabinet and Millwork Installation: The Contractor’s Field Guide

Cabinet and millwork installation is where a project’s finish quality gets judged. Homeowners notice every gap, every uneven door, and every piece of crown molding that does not meet tight at the corner. This is the work that shows up in photos and walkthrough videos. Getting it right requires patience, precision, and a solid understanding of how buildings actually behave.

Walls are never perfectly flat. Floors are never perfectly level. Corners are never perfectly square. The job of a good cabinet and millwork installer is to make everything look perfect anyway. This guide covers the methods and techniques that professionals use to get clean, lasting results.

Pre-Installation Site Check

Before any cabinets arrive on site, spend time checking the space where they are going. Catching problems now saves hours of frustration during install.

Check Walls for Flat and Plumb

Hold a 6-foot straightedge against the wall in multiple spots, both horizontally and vertically. Mark any high spots or dips. Bumps greater than 1/4 inch need to be addressed. You can sand or grind down high spots in drywall or plaster joints. Low spots can be built up with joint compound or shimmed behind the cabinets during installation.

Check walls for plumb with a 4-foot level. Out-of-plumb walls will cause cabinets to lean, creating gaps at the top or bottom. You will need to shim behind the cabinets to bring them plumb, then cover the gap with scribe strips or fillers.

Check the Floor for Level

Use a laser level or a long straight level to check the floor across the entire cabinet run. Find the highest point. This is your starting reference because you will shim everything else up to match it. Mark the highest point and measure up to establish your base cabinet height line.

For a standard 34-1/2 inch base cabinet with a countertop, the finished counter height will be 36 inches from the floor at the high point. At low spots, the cabinets will be shimmed up, and the toe kick will cover the gap.

Check Corners for Square

Use a framing square or the 3-4-5 method to check inside and outside corners. Out-of-square corners affect how cabinets meet at L-shaped or U-shaped layouts. Knowing the angle ahead of time lets you plan filler pieces and scribe cuts.

Verify Rough-In Locations

Confirm that plumbing supply and drain lines, electrical outlets, and gas lines are where the cabinet plan says they should be. Measure from the floor and from the nearest wall to every rough-in point and compare against the cabinet shop drawings. Moving a drain line after cabinets are installed is expensive and destructive.

Layout and Reference Lines

Good installation starts with accurate layout lines on the walls. These are your guide for the entire job.

Establish Your Level Line

Starting from the highest point on the floor, measure up 34-1/2 inches (or whatever the cabinet box height is) and mark the wall. Use a laser level to extend this line across all walls where base cabinets will be installed. This line represents the top of the base cabinet boxes.

For wall cabinets, measure up 54 inches from the finished floor (or 19-1/2 inches above the base cabinet line) to mark the bottom of the wall cabinets. This gives the standard 18-inch backsplash space between counter and wall cabinet bottom.

Mark Stud Locations

Use a stud finder and verify with a small nail or screw. Mark every stud location along the wall cabinet and base cabinet zones. Transfer these marks above and below the cabinet installation area so they are still visible after cabinets are in position. Every cabinet needs to be fastened to studs, not just drywall.

Lay Out the Cabinet Positions

Starting from a corner or a fixed reference point (like a range or sink center), mark the position of each cabinet on the wall. Use the cabinet shop drawings and measure each box width. Account for filler strips at walls, appliance openings, and any special spacing requirements.

Double-check the total layout dimension against the actual wall measurement. If there is a discrepancy, figure out where the extra space goes (usually into filler strips at walls or next to appliances) before you start installing.

Installing Wall Cabinets

Most experienced installers hang wall cabinets first. This gives you clear access without base cabinets blocking your work area. Here is the process.

Install a Ledger Board

Screw a straight 1x4 or strip of plywood to the wall with its top edge at the wall cabinet bottom line. Make sure it is level. This ledger supports the weight of the wall cabinets while you fasten them, and it is much easier and safer than trying to hold a cabinet overhead while driving screws.

Start at a Corner

If the layout includes a corner cabinet, install it first. Set it on the ledger, check for level and plumb, shim as needed, and screw through the cabinet back or hanging rail into wall studs. Use at least two screws per stud, placed through the thickest part of the cabinet back (usually a hanging rail at the top and bottom of the box).

Work Outward from the Corner

Set the next cabinet on the ledger and push it tight against the first cabinet. Clamp the face frames together with the faces perfectly flush. Drill pilot holes and screw the face frames together. Then screw the cabinet back into studs.

Continue this process across the wall. Check level frequently. Even small errors accumulate across a long run of cabinets, and you will end up with a noticeable lean or gap at the far end if you do not stay on top of it.

Shimming Wall Cabinets

When the wall dips behind a cabinet, shim between the cabinet back and the wall at each screw point. Tighten the screws until the cabinet is plumb and the face frame aligns with adjacent cabinets. Do not over-tighten screws into shims or you will bow the cabinet frame.

Score and snap off protruding shims after everything is secure.

Installing Base Cabinets

Base cabinets carry the countertop and all the weight of everything stored inside them. Solid, level installation is critical.

Start at the High Point

Place the first base cabinet at or near the highest point on the floor. Level it side to side and front to back, shimming under the cabinet as needed. Screw through the cabinet back into wall studs.

Work Outward

Like wall cabinets, work from the corner or high point outward. Level each cabinet to the first one, clamp and screw face frames together, and fasten to studs. Keep checking that the tops of all base cabinets are in the same plane. The countertop will expose any inconsistency.

Shimming Base Cabinets

Shim under the front and back of each cabinet at the stud locations. Place shims at both corners of each cabinet for stability. Once all cabinets are level and fastened, trim the shims flush and install the toe kick boards to cover the gap between the floor and cabinet bottom.

Island and Peninsula Cabinets

Cabinets that are not against a wall need to be anchored to the floor. Use a plywood base platform screwed to the subfloor, then fasten the cabinets to the platform. Run any plumbing, electrical, or gas lines up through the platform before setting cabinets. On concrete floors, use concrete screws or expansion anchors for the platform.

Scribing Techniques

Scribing is the process of transferring an irregular surface contour (usually a wall) onto a cabinet piece so you can cut it to fit tight. It is one of the most important skills in finish carpentry.

How to Scribe

1. Position the cabinet where it will be installed, held level and plumb.
2. Open a compass or scribing tool to match the widest gap between the cabinet edge and the wall.
3. Hold the compass so the point follows the wall and the pencil marks the cabinet surface.
4. Run the compass steadily down the wall, keeping it perpendicular to the cabinet edge.
5. Cut along the scribed line with a jigsaw, coping saw, or belt sander.
6. Test the fit and fine-tune with a block plane or sandpaper.

Where to Scribe

• Cabinet stiles that butt against walls
• Filler strips at wall junctions
• Countertop backsplash edges against walls
• Crown molding that meets an uneven ceiling
• Toe kicks on uneven floors

A clean scribe line with zero gap is what separates professional work from hack work. Take your time on these cuts.

Crown Molding, Trim, and Finish Details

The trim work on a cabinet job frames the entire installation. Sloppy trim destroys the look of even perfectly installed cabinets.

Crown Molding

Crown molding at the top of wall cabinets bridges the gap to the ceiling and gives the installation a built-in furniture look. Here is the process:

1. Build a nailing surface. If there is a gap between the top of the wall cabinets and the ceiling, install a sub-fascia board (3/4 inch plywood ripped to width) flat on top of the cabinets. This gives the crown something to nail to.
2. Measure and cut. Measure each run carefully. Crown sits at an angle, so it gets cut differently than flat trim. Set your miter saw to the crown’s spring angle or use a compound miter setup.
3. Cope inside corners. Cut one piece square to butt into the corner. Cut the mating piece at 45 degrees, then cope the profile with a coping saw so it fits over the butt piece. Coped joints stay tight as materials expand and contract.
4. Miter outside corners. Cut both pieces at 45 degrees for outside corners. Pin them together and fill any small gap with caulk.
5. Nail and fill. Use 18-gauge brad nails to attach crown to the sub-fascia and cabinet face frame. Fill nail holes with color-matched putty or wood filler.

Light Rails and Undercab Trim

A light rail molding under the front edge of wall cabinets hides under-cabinet lighting and gives a clean bottom edge. Attach with brad nails from the underside of the cabinet bottom. If the ceiling or cabinet bottom is uneven, scribe the top edge of the light rail for a tight fit.

Fillers, Panels, and End Caps

Exposed cabinet sides get finished end panels to match the door style and color. Apply with construction adhesive and pin nails or screws from inside the cabinet. Fill strips between cabinets and walls or appliances should be scribed to the wall for a seamless look.

Door and Drawer Adjustment

After all cabinets are installed and the countertop is in place, adjust every door and drawer:

• European hinges have three adjustment screws: in/out, up/down, and side to side. Get all doors sitting flush and even with consistent reveals (gaps) between doors.
• Drawer slides also have adjustment capabilities. Soft-close slides should engage smoothly without slamming or failing to close.
• Check alignment from across the room. Stand back 10 feet and look for doors that are cocked, uneven gaps, or drawers that do not sit straight.

Protecting the Work

Finish carpentry and cabinet work gets damaged easily during the remaining phases of construction. Cover countertops with heavy paper or cardboard. Put blue tape over finished edges. Communicate with other trades about what is installed and what needs to be protected. One careless plumber setting a toolbox on a granite counter can create a chip that costs hundreds to repair.

Scheduling and Tracking Cabinet Jobs

Cabinet installations involve multiple phases: site verification, cabinet delivery, base install, wall install, countertop template, countertop install, hardware, and punch list. Missing one step or getting the sequence wrong delays the entire project.

Projul’s scheduling and job tracking tools let you map out each phase, assign crews, and track progress. Your countertop fabricator can see when cabinets are done so they know when to template. Your hardware installer knows when the countertop is going in. Everyone stays in sequence without you making ten phone calls a day.

Curious how it works? Check out pricing or book a quick demo to see the scheduling tools in action.

Common Mistakes and How to Avoid Them

Not checking for level and plumb before starting. Twenty minutes of site checking saves hours of rework.

Skipping the ledger board for wall cabinets. Trying to hold cabinets overhead while driving screws is unsafe and imprecise. Use a ledger.

Using drywall anchors instead of studs. Cabinets are heavy, and they get heavier with dishes and groceries. Every mounting screw goes into a stud. Period.

Ignoring filler calculations. If your cabinet layout is 1/2 inch too wide for the wall, you cannot squeeze it in. Plan fillers and verify measurements before ordering.

Not adjusting doors and drawers. The last 30 minutes of adjustment is what makes the job look professional. Do not skip it.

Forgetting to order hardware. It sounds obvious, but hardware lead times can be weeks on specialty pulls and knobs. Order early.

Wrapping Up

Cabinet and millwork installation is slow, precise work. There are no shortcuts that do not show in the finished product. Check your site before you start, lay out accurate reference lines, install to those lines with patience and care, and spend the time on scribing and trim details that make the job look dialed in.

Good cabinet work gets noticed by homeowners, real estate agents, and anyone who walks into the kitchen. It is the kind of work that generates referrals and repeat business. Take pride in it, and it will take care of you.
